* Product images may appear with optional features or accessories.
VS Series Hydraulic Leveler
Vertical Storing Hydraulic Dock Leveler
Poweramp’s® VS Series vertical storing dock leveler offers unmatched environmental control for customers with food storage or temperature sensitive applications. By storing in the vertical position, the VS Series allows the overhead door to form a perfect seal to the pit floor. VS Series levelers offer improved cleanliness, overhead door protection, increased security, improved productivity, and easy maintenance.
These levelers come in 6’, 6’6”, & 7’ standard widths, and 5’ and 6’ standard lengths with 8’ available. Other lengths may be available upon request. Standard capacities for the VS Series are 40K, 45K, & 50K CIR (Comparative Industry Rating).
SPECIFICATIONS
| VS-65 | 6' x 5' |
|---|---|
| VS-66 | 6' x 6' |
| VS-68 | 6' x 8' |
| VS-655 | 6'6" x 5' |
| VS-656 | 6'6" x 5' |
| VS-658 | 6'6" x 8' |
| VS-75 | 7' x 5 |
| VS-76 | 7' x 6' |
| VS-78 | 7' x 8' |
|
DYNAMIC CAPACITY / COMPARATIVE INDUSTRY RATING |
|---|
| 20,000 / 40,000 |
| 22,500 / 45,000 |
| 25,000 / 50,000 |
PRODUCT DOCUMENTS
- VS Brochure
- VS Spec Sheet
- VS Owner's/User Manual - VS20
- VS Owner's/User Manual - VS3
- VS Series Check Sheet
- Total Site Survey
- Leveler Grade Chart
- Spanish Total Site Survey
- 3-Sided Box / Leveler Installation
- Draft Pad Brochure
- Poweramp Line Card
- VSKS4 Installation Picture Guide
- Poweramp VS Owner’s/User’s Manual (2003-Early 2019)
- Spanish VS Manual - VS20
- Spanish VS Manual - VS3
- Spanish VS Brochure
- Spanish Poweramp Full Product Overview
- Spanish Poweramp VS Manual
-
Safely stored indicator light
A blue light illuminates on the control panel when the leveler is in the vertical position and the secondary prop is engaged.
-
Deck mounted or remote / stanchion mounted pump and motor
The VS leveler can ship with either a remote mounted pump and motor station, or a leveler mounted pump and motor station.
-
Engineered Drawings
Each VS application is unique in its own way. Engineered drawings developed by Poweramp lets all parties know the layout and details necessary for an efficient and working loading dock.
-
Fork truck run off guards
The VS leveler comes with fork truck run off guards to prevent your fork trucks from leaving the leveler deck. This is a vital feature for continuous pit style applications.
-
Push-button controlled up, down and lip function
The VS control station provides push-button activation of the raise and lower function of the leveler as well as infinite control of the leveler lip position.
-
Hydraulic and mechanical storage locks
A mechanical storage lock provides redundant safety while the leveler is in the stored position.
-
Automatic safety prop
A trombeta valve activated prop activates when the leveler is fully stored and automatically releases when the leveler lower button is depressed. This offers secondary support of the leveler and added protection to your employees
-
Connect Online
Option to connect to myQ Dock Management and view the leveler activity online.
